Single side black/green cooling pad

Short Description:

Very hot and very dry climates could have devastating effects on of livestock , plants, and humans productivity. Evaporative cooling has proven to be one of the most reliable and economical methods to maintain optimum temperature and humidity.The temperature-humidity exchange process between water and air:Because water temperature is lower than air temperature exhausted from outside to inside workshop, evaporating water will absorb the heat of air and make water hotter, oppositely air becomes cooler and humidity in air increases suitalbly.


Product Detail

Product Tags

Selling Point:

Can be painted with black, green, blue, yellow and other colors according to customer requirements

Description:

When the air moves through the ventilation device, the system passes through a wet cooling pad and the air humidity increases. The energy that is lost in water evaporation results in reduction of air temperature. Evaporative cooling is a natural process and is used throughout the world for following reasons :
-High Temperature Reduction
-Low energy consumption
-Low Purchasing and Installation Cost
-Good performance even in areas where water quality is poor
-Low maintenance cost
The cooling pads are made of high water retention cellulose and are designed to provide the maximum water-air mixture with the lowest possible pressure drop.Cellulose retains more water per unit volume. It is made from pure cellulose only. Cellulose humate hardening resin is non-toxic when in contact with water

Cooling Pad “Black+” is developped specially for harsh and tough condition. Special “Black+” protective coating prevents Cooling pad surface from constantly exposing to extreme environment such as dirt, sand storm, and risk of bacterial and algae growth. “Black+” protective coating is also durable and strong enough for frequent surface cleaning. Enhanced with special anti-friction modifier,cooling pad “Black+” is tough and can be cleaned effortlessly. This will ensure not only its long service life even under harsh condition, but also its optimum efficiency for a long time.
Pad “Black+” is developped on two basic models including Pad 7090 and Pad 7060. For this reason, aside from special “Black+” protective coating, its shape, structure, standard dimension, declination of wave, angle of cut-off and saturation efficiency or pressure drop are similar to Pad 7090 or Pad 7060.
Pad “Black+” is developped specially for harsh and tough condition. It is an ideal evaporative cooling media for gas turbine inlet, textile factories, harsh water condition, locations exposed to sand storm and the application where risk of algae and bacterial growth is high. With special protective coating in Pad “Black+”, the surface will not allow algae or bacteria or mineral deposits to anchor themself.

iamges5
images4
iamges3
QQ图片20220330162158
iamges2
QQ图片20220330162311
iamges7
iamges3
