LRS-35W
·Miniature size and 1U low profile,low weight
·Protections:Short circuit/Overload/Over voltage
·Cooling by free air convection
·No load power consumption＜0.5W
·Operating altitude up to 5000 meters（Note6）
·LED indicator for power on
·100% full load burn-in test
·High efficiency,long life and high reliability
·3 years warranty
| Model | LRS-35-5 | LRS-35-12 | LRS-35-15 | LRS-35-24 | LRS-35-36 | LRS-35-48 | |
| output | DC voltage | 5V | 12V | 15V | 24V | 36V | 48V |
| Rated current | 7A | 3A | 2.4A | 1.5A | 1A | 0.8A | |
| Current range | 0~7A | 0~3A | 0~2.4A | 0~1.5A | 0~1A | 0~0.8A | |
| Rated power | 35W | 36W | 36W | 36W | 36W | 38.4W | |
| Ripple&noise | 100mVp-p | 120mVp-p | 120mVp-p | 150mVp-p | 200mVp-p | 200mVp-p | |
| DC voltage ADJ. range | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% | |
| Voltage toleranceNote.3 | ±3% | ±2% | ±1% | ±1% | ±1% | ±1% | |
| Line regulationNote.4 | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Load regulationNote.5 | ±2% | ±1% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Setup,rise,hold up time | 800ms,30ms,30ms/230VAC(full load) | ||||||
| input | Voltage range | 90~264VAC，127～373VDC | |||||
| Frequency range | 47~63HZ | ||||||
| AC current | 0.7A/115VAC 0.42A/230VAC | ||||||
| Inrush current | Cold start 45A/230VAC | ||||||
| Efficiency | 83% | 86% | 87% | 88% | 89% | 90% | |
| Leakage current | <0.75mA/240VAC | ||||||
| protection | overload | Rated output power110%~150% start over load protection | |||||
| protection type:hiccup mode，auto-recovery after fault condition is removed | |||||||
| Over voltage | Rated output voltage 115%~135% Start over voltage protection | ||||||
| Protection type：hiccup mode，auto-recovery after fault condition is removed | |||||||
| environment | Working temp,humidity | -30℃～+70℃(Please refer to“derating curve”) 20%~90%RH Non-condensing | |||||
| Storage temp,humidity | -40℃~+85℃，10%~95%RH non-condensing | ||||||
| Withstand vibration | 10~500HZ，2G10min/1cycle，period for 60 minutes，each axes | ||||||
| safety | Withstand voltage | I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:1.25KVAC | |||||
| Isolation resistance | I/P-O/P,I/P-FG,O/P-FG:100Mohms/500VDC | ||||||
| Fit standard | Safety standards | Compliance to UL60950-1,TUV EN60950-1,GB4943 | |||||
| EMC emission | Compliance to EN55032(CISPR22)Class A，GB9254 Class B,EN55014,EN61000-3-2,3 | ||||||
| EMC immunity | Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024,EN61000-6-1 | ||||||
| others | Dimension | 99*82*30mm（L*W*H） | |||||
| Weight/packing | 0.23kg/60pcs/14.8kg/0.025m³/0.88CUFT | ||||||
| MTBF | ≥720K hrs min. MIL-HDBK-217F(25℃) | ||||||
| note | 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃of ambient temperature.2. Ripple & noise are measured at 20MHz of bandwidth by using a 12″ twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.3. Tolerance : includes set up tolerance, line regulation and load regulation.
4.Line regulation is measured from low line to high line at rated load. 5.Load regulation is measured from 0% to 100% rated load 6.The ambient temperature derating of 5℃/1000 m is needed for operating altitude greater than 2000m(6500ft) 7.The power supply is considered as a component which will be installed into a finalequipment.The final equipment must be re-confirmed that it still meets EMC directives.For guidance on how to perform these EMC tests. |
||||||
