ITU-T G652D SM optical fiber
G.652.D Standard Single-Mode Optical Fiber
Product Introduction
Standard single-mode fiber is also called non-dispersion-shifted single-mode fiber with extended wavelength band that is currently the most widely used optical fiber. The working wavelength can be from 1310nm and 1550nm.
Application Scenarios
The wider wavelength range is suitable for high-speed networks.
Accurate mode field diameter (MFD) characteristics to ensure low fusion loss and good compatibility.
Performance Features
100G & B100G high-speed, long-distance and long-span backbone network.
Large bandwidth metropolitan area network and access network.
Product Specification
| Parameter | Conditions | Units | Value |
| Optical | |||
| Attenuation | 1310 nm | dB/km | ≤ 0.350 |
| 1383 nm | dB/km | ≤ @ 1310nm | |
| 1490nm | dB/km | ≤ 0.250 | |
| 1550 nm | dB/km | ≤ 0.210 | |
| 1625 nm | dB/km | ≤ 0.240 | |
| Attenuation vs. Wavelength | 1310 nm VS. 1285- 1330 nm | dB/km | ≤ 0.04 |
| 1550 nm VS. 1525- 1575 nm | dB/km | ≤ 0.03 | |
| 1550 nm VS. 1480- 1580 nm | dB/km | ≤ 0.04 | |
| Zero Dispersion Wavelength | nm | 1300 – 1324 | |
| Zero Dispersion Slope | ps/(nm2 ·km) | 0.073 – 0.092 | |
| Chromatic Dispersion | 1290~ 1330nm | ps/nm.km | |
| Dispersion | 1550 nm | ps/(nm·km) | |
| 1625 nm | ps/(nm·km) | 17.2 – 23.7 | |
| Polarization Mode Dispersion (PMD) | ps/√km | ≤ 0.2 | |
| Cut-offWavelength λcc | Cable Cut-off wavelength(λ cc) | nm | ≤ 1260 |
| Fiber Cut-off wavelength(λ cc) | nm | 1150-1330 | |
| Mode Field Diameter (MFD) | 1310 nm | μm | 9.2 ± 0.4 |
| 1550 nm | μm | 10.4 ± 0.5 | |
| Attenuation Discontinuity | 1310 nm | dB | ≤ 0.03 |
| 1550 nm | dB | ≤ 0.03 | |
| Bidirectional Attenuation | 1310 nm | dB/km | ≤ 0.04 |
| 1550 nm | dB/km | ≤ 0.04 | |
| Geometrical | |||
| Cladding Diameter | μm | 125±0.7 | |
| Cladding Non-Circularity | % | ≤ 1.0 | |
| Core/Cladding Concentricity Error | μm | ≤0.5 | |
| Coating Diameter (Uncolored) | μm | 242±7 (standard) | |
| μm | 200± 10 (optional) | ||
| Coating/Cladding Concentricity Error | μm | ≤ 12 | |
| Curl | m | ≥ 4 | |
| Environmental (1550nm, 1625nm) | |||
| Temperature Cycling | -60C to +85C | dB/km | ≤ 0.03 |
| High Temperature & High Humidity | 85C, 85% RH, 30days | dB/km | ≤ 0.03 |
| Water Immersion | 23C, 30days | dB/km | ≤ 0.03 |
| High Temperature Aging | 85C, 30days | dB/km | ≤ 0.03 |
| Mechanical | |||
| Proof Stress | - | GPa | 0.69 |
| Coating Strip Force * | Peak | N | 1.3 – 8.9 |
| Average | N | 1.0 – 5.0 | |
| Tensile Strength | Fk=50% | GPa | ≥ 4.00 |
| Fk= 15% | GPa | ≥ 3.20 | |
| Dynamic Fatigue (Nd) | - | - | ≥ 20 |
| Macrobending Loss | |||
| Ø32 mm×1 t | 1550 nm | dB | ≤ 0.05 |
| 1625 nm | dB | ≤ 0.05 | |
| Ø60 mm×100 t | 1550 nm | dB | ≤ 0.05 |
| 1625 nm | dB | ≤ 0.05 | |
| * The peak peel force ofthe coating is 0.6-8.9N, and the average value is 0.6-5.0N when the coating diameter is 200± 10. | |||
