Factory selling 4×4 import Germany(MAN)TGM 18.320 Compressed air foam fire truck

Short Description:


Product Detail

Product Tags

AP45 compressed air foam fire truck is designed by combining the advanced concepts of domestic and foreign fire trucks and fire fighting actual combat innovation. It has powerful fire extinguishing functions and comprehensive rescue capabilities. The intelligent control level is at the domestic advanced level.

The whole vehicle is equipped with an advanced compressed air foam system and adopts an integrated control panel, which has the characteristics of convenient and fast operation, high fire extinguishing efficiency, environmental protection, and small secondary losses caused by fire extinguishing; aluminum alloy body, light weight, high strength, anti-corrosion Good performance; the equipment box is made of special aluminum alloy shelf plates, which can be freely adjusted up and down, and various installation structures such as pull-out boards, trays, and high-strength plastic baskets are provided according to different equipment. The space utilization rate is high, and the equipment is equipped with It is more convenient to use; it is equipped with a number of safety protection measures to achieve all-round protection and ensure the safety and reliability of the vehicle.

Equipped with fire pumps, winches, lifting lighting systems, demolition tools, life-saving appliances and other types of equipment, it is the main vehicle for fire fighting, flood control, traffic accidents and other disasters.

Chassis Information

Chasis Model:Germany MAN TGM 18.320 4X4

Engine Model/Type:MAN D08 series Six-cylinder in-line turbocharged intercooled electronically controlled common rail diesel

Engine power:235 kW

Engine torque:1250 Nm

Max speed:≤100km/h(Electronic speed limit)

Wheel base:4425 mm

Emission standard:Euro 6

Transmission:Automatic transmission

Front axle/rear axle allowable load:7000kg/11000kg

Outer dimension

L×W×H:≤8700×2520×3500mm

Wheel base:4425mm

Driving and dynamic performance parameters

Power:235kW

Passengers:1+2+4

Emission Standard:Euro 6

Full loading weight:≤16000kg

Extinguisher capacity

Water tank capacity:4000±100L

Foam A capacity:500±50L

Foam B capacity:500±50L

Fire performance parameters

Pump flow:3600L/min@1.0MPa

Monitor flow:≥3000L/min

Monitor range:≥60m

CAFS system pressure:0.85MPa

Air compressor flow:56L/S

Foam pump flow:≥12.5L/min

Winch parameter

Max tension:50.0KN

Power generation lighting system parameters

Generator power:5kW

Parameters

Model Germany MAN TGM 18.320 4X4
Chassis Power(KW) 235 kW
 Emission     Standard Euro6
Wheelbase(mm) 4425mm
Passengers 1+2+4(double row four doors)
Water tank capacity(L) 4000±100L
Foam A capacity 500±50L
Foam B capacity 500±50L
Fire pump 3600L/min@1.0MPa
Fire monitor ≥3000L/min
Water range(m) ≥ 60m
