China Elevated Steel Domestic Water Reservoir Tank Manufacturer and Supplier

Elevated Steel Domestic Water Reservoir Tank

Short Description:

Elevated Domestic Water Tank To increase the water pressure and save ground space, some projects require elevated water tank with tower stand. All kinds of water tanks can be used as elevated water tank. Min. Order: 1 Cubic Meter Size: Customized Shipping: Support Sea fright

Send email to us

Product Detail

Product Tags

WHAT IS ELEVATED WATER TANK?

We design the tank tower by hot dipped galvanized steel structure with bolted connection. It makes the installation work much easier and high efficiency. The water tank body and tower stand body are designed as one union, which makes it higher strength and longer lifetime.

Technical parameters

Normally it needs to designed by our technician as client’s requests.

Clients will supply the information like size of water tank and tower height. And local wind power, wind speed and Max.earthquake level are also necessary actors to consider during designation.

THE PRODUCT CONTAINS

1.Main steel frame; 2.With fence around tower; 3.Platform with walk-way; 4.Ladder with safety cage;

ADVANTAGES OF GRP WATER TANK

★ Increase the water pressure and save ground space;

★ No Rust & Long Service Life;

★ Food Grade Material & Healthy Uses;

★ Flexible Design & Free Combination;.

★ Reasonable Price & Considerate Service;

★ Easy to transport, install and maintain;

★ Working Life is over 50 years with proper maintenance;

ELEVATED WATER TANK SIZE LIST IN

2m High （mm）				2.5m High（mm）				3m High（mm）
Volume M³	L	W	H	Volume M³	L	W	H	Volume M³	L	W	H
4	1000	2000	2000	5	1000	2000	2500	6	1000	2000	3000
8	2000	2000	2000	10	2000	2000	2500	12	2000	2000	3000
12	3000	2000	2000	15	3000	2000	2500	18	3000	2000	3000
16	4000	2000	2000	20	4000	2000	2500	24	4000	2000	3000
20	5000	2000	2000	25	5000	2000	2500	30	5000	2000	3000
18	3000	3000	2000	22.5	3000	3000	2500	27	3000	3000	3000
24	4000	3000	2000	30	4000	3000	2500	36	4000	3000	3000
30	5000	3000	2000	37.5	5000	3000	2500	45	5000	3000	3000
36	6000	3000	2000	45	6000	3000	2500	54	6000	3000	3000
42	7000	3000	2000	52.5	7000	3000	2500	63	7000	3000	3000
32	4000	4000	2000	40	4000	4000	2500	48	4000	4000	3000
40	5000	4000	2000	50	5000	4000	2500	60	5000	4000	3000
48	6000	4000	2000	60	6000	4000	2500	72	6000	4000	3000
56	7000	4000	2000	70	7000	4000	2500	84	7000	4000	3000
64	8000	4000	2000	80	8000	4000	2500	96	8000	4000	3000
72	9000	4000	2000	90	9000	4000	2500	108	9000	4000	3000
50	5000	5000	2000	62.5	5000	5000	2500	75	5000	5000	3000
60	6000	5000	2000	75	6000	5000	2500	90	6000	5000	3000
70	7000	5000	2000	87.5	7000	5000	2500	105	7000	5000	3000
80	8000	5000	2000	100	8000	5000	2500	120	8000	5000	3000
90	9000	5000	2000	112.5	9000	5000	2500	135	9000	5000	3000
100	10000	5000	2000	125	10000	5000	2500	150	10000	5000	3000
120	10000	6000	2000	150	10000	6000	2500	180	10000	6000	3000
140	10000	7000	2000	175	10000	7000	2500	210	10000	7000	3000
160	10000	8000	2000	200	10000	8000	2500	240	10000	8000	3000
180	10000	9000	2000	225	10000	9000	2500	270	10000	9000	3000
200	10000	10000	2000	250	10000	10000	2500	300	10000	10000	3000
Remarks: For table limits,we can’t list all sizes here. we can design and produce as your any size.Our Elevated Water Tank with Size from 1M³ to 5000M³.More questions, please contact us!

CUSTOMERS FEEDBACK

WIDELY USED OF OUR ELEVATED WATER TANK

Elevated Water Tanks supplied by our company are installed more than 130 countries, such as: Ghana, Philippines, USA, Malaysia, Indonesia, France, Mongolia, Ethiopia, Nigeria, Myanmar, South Sudan, Susan, South Africa, UAE, Cambodia, Libya, India, South Korea and so on.

Our company consistently adheres to the concept of “customer first, Integrity first, quality first, service first.”

Won international customer’s unanimous praise.

|–>
